Duct Smoke Detector Sampling Tube Installation

Drilling template 4. Ensure that the sampling tube is angled downward from the duct smoke detector to allow for moisture drainage away from the detector. Ensure that the sampling tube is angled downward from the duct smoke detector to allow for moisture drainage away from the detector.

diy closet organizer with drawers diy dining bench with back plans dining room table sets walmart dining table wall bed does transition pieces included in carpet install disney princess lights and sounds trike drywall ceiling repair kit does lowes sell carpet padding

Location And Installation Of Detectors In Air Duct Systems Fire Alarms Certified

True Duct Smoke Detectors With Relay Output And Analogue Output Vsd Series Ventilation Control Products Sweden Ab

Midsouthelectronics Com Photoelectric Smoke Duct Detector And Sampling Tube Federal Signal

Source

Duct Smoke Detectors

Ari Catalog Hvac Installation Accessories Duct Smoke Detectors Sampling Tubes

Drill a 3 4inch hole in the duct opposite the hole already cut for the sampling tube.

Duct smoke detector sampling tube installation. Duct smoke detector a. Sensor power board assembly and covers sensor head is factory installed 2. Air is introduced to the duct smoke detector s sensing chamber through a sampling tube that ext ends into the hvac duct and is directed back into the ventilation system through an exhaust tube. The sampling tube end cap included with the detector is critical to proper operation of the duct smoke detector.

The difference in air pressure between the two tubes pulls the sampled air through the sensing chamber. 3 contents of the duct smoke detector kit 1. Use 4 mounting screws 4 12 x 1 2 sheet metal screws packaged in installation kit to secure the housing to the air duct. The sampling tube should be angled at least 1 4 downward for every 12 of duct width per figure 4.

Verify this by checking specifications of installation and if necessary use an alnor model 6000p velocity meter or equivalent to check the air velocity. Once any sampling tube length adjustments are made plug the end of the sampling tube with the provided end cap. Sampling tubes install from front and rear compatible with existing accessories able to address detector per code switches on sensor head. Move duct housing sampling tube assembly to desired location.

Sampling tube assembly see figure 2 the duct detectors are designed for use in ducts where the air velocities are from 300 to 4000 feet per minute. Drill a 3 4inch hole in the duct opposite the hole already cut for the sampling tube. Sampling tube connectors are equipped with set screws which allow the tubes to be mounted only in directions shown in figure 2. The sampling tube should be angled at least 1 4 downward for every 12 of duct width per figure 4.

Locate the sensor so its sampling tube is positioned in a straight length of square duct between six and ten duct widths from any bends or obstructions as shown in the diagram below. To ensure correct operation install the superduct duct smoke detector using the following guidelines. See figure 12 for sensor and controller dimensions. The end cap is needed to cre ate the proper air flow to the sensor of the duct smoke detector.

Three 10 sheet metal screws for mounting 3.
